Q2-F3X-1/8-01-MS100FT by qualtek electronics
Image is representational - see manufacturer specifications
Qualtek Electronics Authorized Distributor

Q2-F3X-1/8-01-MS100FT

The Q2-F3X-1/8-01-MS100FT is a flexible, flame-retardant polyolefin heat shrink tubing with a 3:1 shrink ratio designed for electrical insulation and mechanical protection. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tray Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The Q2-F3X-1/8-01-MS100FT is a highly flexible, flame-retardant polyolefin heat shrink tubing. This 1/8-inch tubing features a 3:1 shrink ratio, reducing from a minimum supplied inside diameter of 3.2 mm to a maximum recovered diameter of 1.0 mm with a final wall thickness of 0.55 mm. It is rated for an operating temperature range of -55°C to +135°C and begins to shrink at 70°C. Key electrical properties include a dielectric strength over 20 kV/mm and a 600V rating. Due to its high flexibility and shrink ratio, it is ideal for electrical insulation, bundling, marking, and providing mechanical and corrosion protection, especially over irregular shapes.

Search Keywords: Q2F3X1801MS100FT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Qualtek Electronics
Part No:
Q2-F3X-1/8-01-MS100FT
Unit of Measure:
Per Spool
RoHS:
Yes
HTS:
3926909985
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
5
Package Type:
Tray
Type:
Tubing
Body Material:
Polyolefin
Shrink Wall Type:
Thin
Styles:
Straight
Shrink Ratio:
3:1
Dielectric Strength:
20 KV/mm
Operating Temperature:
-55 to 135 °C

IN STOCK: 90 Spools

Ships today, if you order in

Minimum Order Quantity: 5 Spools

Multiple: 5 Spools

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
5
$8.58
25
$6.97
50
$6.79
100
$6.04
250
$5.55
500
$5.39
1,000 +
$5.22
