CFM-8015V-127-320

Name: CFM-8015V-127-320
Brand: Same Sky®
SKU: 52141070
Price: 31.55 USD
Availability: InStock

80 mm x 80 mm Dc Axial Fan, omniCOOL™ Bearing - 12 V, 149 mA, 80 x 80 x 15 mm, Dc Fan ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Tray Packaging

Discontinued & Replaced

Certificate of Compliance

DESCRIPTION

CFM-8015V-127-320 is a 12 Vdc DC axial fan from the CFM-80V series featuring an 80 x 80 x 15 mm frame with omniCOOL bearing system and 4-pole DC brushless motor design. The fan operates at a rated speed of 2700 RPM (±10%) with an input current of 149 mA and maximum power consumption of 1.79 W, delivering 33.8 CFM of airflow at 0 inch H2O static pressure with a maximum static pressure capability of 0.11 inch H2O. The unit produces a maximum noise level of 32.0 dBA and operates reliably across an input voltage range of 4.5 to 13.8 Vdc, with an operating temperature range of -10°C to +70°C. This fan is ideal for compact cooling applications in electronics, telecommunications, and industrial equipment where space is limited and consistent thermal management is required.

Product Highlights:

Potential Applications:

Search Keywords: CFM8015V127320

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Same Sky®

Part No:

CFM-8015V-127-320

Unit of Measure:

Per Each

RoHS:

Yes

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
