CFM-8020V-133-380

Name: CFM-8020V-133-380
Brand: Same Sky®
SKU: 52141091
Price: 136.5 USD
Availability: InStock

DC Fan - 12 V - 150 mA - 80 x 80 x 20 mm ...

View Datasheet

Ask the Datasheet

RoHS Compliant

tray Packaging

Discontinued & Replaced

Certificate of Compliance

DESCRIPTION

CFM-8020V-133-380 is a 12 Vdc DC axial fan designed for efficient thermal management in electronic systems. It features an 80 x 80 x 20 mm frame size with a 4-pole DC brushless motor and omniCOOL bearing system for reliable operation. The fan delivers an airflow of 36.0 CFM at a rated speed of 3300 RPM with a maximum static pressure of 0.18 inch H2O and noise level of 38.0 dBA. Operating within a voltage range of 6-13.8 Vdc, it consumes a maximum input current of 150 mA and power of 1.80 W. This fan includes auto restart protection as standard and is suitable for cooling applications in electronics, servers, and industrial equipment.

Product Highlights:

Potential Applications:

Search Keywords: CFM8020V133380

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Same Sky®

Part No:

CFM-8020V-133-380

Unit of Measure:

Per Each

RoHS:

Yes

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
