BCS-104-L-S-TE by samtec
Image is representational - see manufacturer specifications
Samtec Authorized Distributor

BCS-104-L-S-TE

Board-To-Board Connector - 2.54 mm - 4 Contacts - Receptacle - Through Hole - 1 Row. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The BCS-104-L-S-TE is a 4-pole 1-row 2.54mm Tiger Claw™ Pass-through Socket Strip with 10µinch (0.25µm) gold-plated phosphor bronze contacts and matte tin plated tail. Liquid crystal polymer insulator and top entry body orientation. The BCS series pass-through socket strip is compatible with DW, EW, HMTSW, HTSW, HW-SM, HW-TH, LCW, MTLW, MTSW, PHT, TSM, TSS, TSW, ZSS and ZW series connectors.

Search Keywords: BCS104LSTE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
BCS-104-L-S-TE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Socket Strip
Body Orientation:
Straight
Gender:
SKT
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
4
Maximum Voltage Rating:
475 VAC
Maximum Current Rating:
4.6/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 4,458

Can Ship immediately

Manufacturer Stock: 419   can ship 10/23/26

Minimum Order Quantity: 25

Factory Lead-Time 2 Weeks can ship 10/26/26

Price (USD)

Qty
Unit Price
25
$1.283
250
$1.130
500
$1.008
1,000
$0.953
2,500
$0.949
5,000
$0.853
7,500
$0.851
10,000 +
$0.849
