BNC7T-J-P-HN-RA-BH2D by samtec

BNC7T-J-P-HN-RA-BH2D

Samtec

Conn BNC RCP 0Hz to 6GHz 75Ohm Solder RA Thru-Hole Gold Kit ...

Datasheet
RoHS Compliant
Kit Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SAMTEC part BNC7T-J-P-HN-RA-BH2D is a high-quality connector designed for BNC applications. This right-angle, 75-ohm receptacle connector offers excellent performance from 0Hz to 6GHz. It features a solder termination design and is suitable for through-hole mounting. The connector is constructed with gold-plated contacts, ensuring superior conductivity and reliability. The BNC7T-J-P-HN-RA-BH2D comes as a complete kit, making it convenient for various installation projects. It is an ideal choice for professionals seeking a robust and versatile BNC connector solution with exceptional signal integrity in a wide range of applications.

Search Keywords: BNC7TJPHNRABH2D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
BNC7T-J-P-HN-RA-BH2D
RoHS:
Yes
HTS:
8536694010
COO:
MY
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Kit
Type:
BNC
Impedance:
75 Ohm
Operating Frequency:
0 to 6 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 125 °C
Dimension:
29 x 10.8 mm

IN STOCK: 273

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
5
$18.084
25
$10.337
100
$7.319
250
$7.151
500
$6.186
1,000
$5.941
2,500
$5.911
5,000 +
$5.896
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
