ESQ-120-12-G-D by samtec
Image is representational - see mfr. specs

ESQ-120-12-G-D

Samtec

Board-To-Board Connector - Elevated - 2.54 mm - 40 Contacts - Receptacle - Through Hole. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ESQ-120-12-G-D is a 40-pole 2-row 2.54mm Elevated Socket Strip with 20µinch (0.51µm) gold-plated phosphor bronze contacts and glass filled polyester insulator. The ESQ series socket strip is compatible with DW, EW, HHSC, HMTSW, HTSS, HTSW, HW-SM, HW-TH, LCW, MTLW, MTSW, PHT, TSM, TSS, TSSH, TSW, ZSS and ZW series connectors. This connector has operating temperature range from -55°C to 125°C.

Search Keywords: ESQ12012GD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
ESQ-120-12-G-D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Tube
Type:
Elevated Socket
Body Orientation:
Straight
Gender:
SKT
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
40
Maximum Voltage Rating:
550 VAC
Maximum Current Rating:
5.7/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 424

Can Ship immediately

Manufacturer Stock: 105   can ship 5/4/26

On Order: 1,000   can ship 6/1/26

Minimum Order Quantity: 5

Factory Lead-Time 2 Weeks can ship 5/6/26

Price (USD)

Qty
Unit Price
5
$6.95
25
$5.98
50
$5.25
100
$4.38
250
$4.09
500
$4.04
1,000
$3.99
2,500 +
$3.76
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
