FTSH-105-01-L-D by samtec
Image is representational - see manufacturer specifications
Samtec Authorized Distributor

FTSH-105-01-L-D

Board-To-Board Connector - 1.27 mm - 10 Contacts - Header - Through Hole - 2 Rows. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The FTSH-105-01-L-D is a 10-pole 2-row 1.27mm Micro Terminal Strip with 10μinch (0.25μm) gold-plated phosphor bronze contacts and LCP insulator. The FTSH series terminal strip is compatible with CLP, FFSD and FLE series connectors. Temperature range from -55°C to 125°C.

Search Keywords: FTSH10501LD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
FTSH-105-01-L-D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
Tube
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
1.27 mm
Number of Contacts:
10
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1.75/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 29,301

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
25
$1.0414
250
$0.8762
500
$0.7737
1,000
$0.6742
2,500
$0.5698
5,000
$0.5165
7,500
$0.5135
10,000 +
$0.5009
Log in for special pricing

Tools/3D Models

Product Guides
