SHF-110-01-L-D-SM-K-TR by samtec

SHF-110-01-L-D-SM-K-TR

Samtec

Conn Shrouded Header (4 Sides) HDR 20 POS 1.27mm Solder ST Top Entry SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SAMTEC SHF-110-01-L-D-SM-K-TR is a high-quality shrouded header that is designed for effective and reliable connections. It features a 20-posiiton header with a 1.27mm pitch, making it suitable for a wide range of applications. The header is designed for surface mount technology (SMT) and provides a top entry for easy installation. It is constructed with solder tails for a secure and durable soldering connection. The shrouded design ensures proper alignment and prevents accidental mismating. The SHF-110-01-L-D-SM-K-TR is packaged on tape and reel for convenient and efficient handling.

Search Keywords: SHF11001LDSMKTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
SHF-110-01-L-D-SM-K-TR
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Reel
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Surface Mount
Pitch:
1.27 mm
Number of Contacts:
20
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1.75/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 908

Ships today, if you order in

Manufacturer Stock: 19,524   can ship 12/5/25

Minimum Order: 10

Factory Lead-Time 2 Weeks can ship 12/5/25

Price (CAD)

Qty
Unit Price
10
$5.727
25
$4.655
100
$3.874
250
$3.859
500
$3.461
1,000
$3.094
2,000 +
$2.788
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
