SHF-120-01-L-D-SM by samtec
Image is representational - see manufacturer specifications
Samtec Authorized Distributor

SHF-120-01-L-D-SM

Conn Shrouded Header (4 Sides) HDR 40 POS 1.27mm Solder ST Top Entry SMD Tube

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Conn Shrouded Header (4 Sides) HDR 40 POS 1.27mm Solder ST Top Entry SMD Tube

Search Keywords: SHF12001LDSM

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
SHF-120-01-L-D-SM
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
Tube
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Surface Mount
Pitch:
1.27 mm
Number of Contacts:
40
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1.75/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 127

Ships today, if you order in

Manufacturer Stock: 16   can ship 11/16/26

Minimum Order Quantity: 10

Factory Lead-Time 2 Weeks can ship 11/16/26

Price (USD)

Qty
Unit Price
10
$3.14
50
$3.00
100
$2.94
250
$2.85
500
$2.54
1,000
$2.29
2,500 +
$2.03
Log in for special pricing
