SSQ-104-01-G-D by samtec
Image is representational - see mfr. specs

SSQ-104-01-G-D

Samtec

The SSQ-104-01-G-D is a double-row, 8-pin through-hole socket with a 2.54 mm pitch and square tails for board-to-board connections. ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SSQ-104-01-G-D is a through-hole square tail post socket designed for reliable interconnects. It is configured in a double-row layout with 4 pins per row on a (2.54 mm) .100" pitch. This component features phosphor bronze contacts with 20 µ" (0.51 µm) gold plating and an insulator made of black liquid crystal polymer. It has a current rating of 6.3 A per pin, a voltage rating of 465 VAC / 655 VDC, and an operating temperature range of -55 °C to +125 °C. This socket is ideal for applications requiring durable, high-cycle connections and mates with various headers such as the TSW and TSM series.

Search Keywords: SSQ10401GD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
SSQ-104-01-G-D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Type:
Socket Strip3594
Body Orientation:
Straight3574
Gender:
SKT3578
Mounting:
Through Hole3586
Pitch:
2.54 mm
Number of Contacts:
8
Maximum Voltage Rating:
6553584VDC,4653584VAC
Maximum Current Rating:
6.3/Contact A
Termination Method:
Solder3593
Operating Temperature:
-55 to 125 °C

IN STOCK: 1,725

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
10
$2.010
100
$1.225
250
$1.211
500
$1.076
1,000
$1.039
2,500
$1.034
5,000
$1.029
7,500 +
$1.024
