SSW-104-01-G-D by samtec

SSW-104-01-G-D

Samtec

Board-To-Board Connector - Dual - 2.54 mm - 8 Contacts - Receptacle - Through Hole - 2 Rows. ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SSW-104-01-G-D is a 8-pole 2-row 2.54mm Through-hole SQ Post Socket Strip with gold-plated phosphor bronze contacts and LCP insulator. The SSW series straight pin socket strip compatible with DW, EW, HCMD, HCMS, HHSC, HMTSW, HTSS, HTSW, HW-SM, HW-TH LCW, MTLW, MTSW, PHT, TLW, TSM, TSS, TSSH, TSW, ZSS and ZW connectors. This connector has high operating temperature range of -55°C to 125°C.

Search Keywords: SSW10401GD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
SSW-104-01-G-D
RoHS:
Yes
HTS:
8536694040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Type:
Socket Strip3594
Body Orientation:
Straight3574
Gender:
SKT3578
Mounting:
Through Hole3586
Pitch:
2.54 mm
Number of Contacts:
8
Maximum Voltage Rating:
6553584VDC,4653584VAC
Maximum Current Rating:
4.7/Contact A
Termination Method:
Solder3593
Operating Temperature:
-55 to 125 °C

IN STOCK: 784

Ships today, if you order in

Minimum Order: 10

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
10
$1.930
100
$1.201
250
$1.188
500
$1.055
1,000
$1.018
2,500
$1.012
5,000
$0.874
7,500 +
$0.870
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
