SSW-113-01-G-D by samtec
Image is representational - see manufacturer specifications
Samtec Authorized Distributor

SSW-113-01-G-D

Board-To-Board Connector - 2.54 mm - 26 Contacts - Receptacle - Through Hole - 2 Rows. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Bulk Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The SSW-113-01-G-D is a 26-pole 2-row 2.54mm Through-hole SQ Post Socket Strip with gold-plated phosphor bronze contacts and LCP insulator. The SSW series straight pin socket strip compatible with DW, EW, HCMD, HCMS, HHSC, HMTSW, HTSS, HTSW, HW-SM, HW-TH LCW, MTLW, MTSW, PHT, TLW, TSM, TSS, TSSH, TSW, ZSS and ZW connectors. This connector has high operating temperature range of -55°C to 125°C.

Search Keywords: SSW11301GD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
SSW-113-01-G-D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Type:
Socket Strip
Body Orientation:
Straight
Gender:
SKT
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
26
Maximum Voltage Rating:
550 VAC
Maximum Current Rating:
5.7/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 562

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
5
$4.23
50
$3.48
100
$3.18
250
$3.16
500
$2.51
1,000
$2.20
2,500
$1.69
5,000 +
$1.52
