TSM-105-01-S-DV-P-TR by samtec
Image is representational - see mfr. specs

TSM-105-01-S-DV-P-TR

Samtec

The TSM-105-01-S-DV-P-TR is a 10-pin, double-row, vertical surface-mount header with a 2.54 mm pitch and .025" square posts. ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TSM-105-01-S-DV-P-TR is a double-row, vertical SMT header from the TSM series, designed for board-to-board and cable-to-board connections. It features 10 phosphor bronze terminals arranged in two rows of five, with a 2.54 mm pitch and a post height of 5.84 mm. The terminals are plated with 30 µ" gold on the post and matte tin on the tail over a nickel underplate, all housed within a black liquid crystal polymer insulator. This header is rated for 475 VAC, has a current rating up to 5.4 A per pin when mated with an SSM connector, and operates over a temperature range of -55 °C to +125 °C. Equipped with a plastic pick-and-place pad and supplied in tape and reel packaging for automated assembly, it is ideal for various high-reliability electronic applications requiring robust SMT connections.

Search Keywords: TSM10501SDVPTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
TSM-105-01-S-DV-P-TR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
1
Package Type:
Reel
Type:
Unshrouded Header3594
Body Orientation:
Straight3574
Gender:
HDR3578
Mounting:
Surface Mount3586
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
4753584VAC
Maximum Current Rating:
5.4/Contact A
Termination Method:
Solder3593
Operating Temperature:
-55 to 125 °C
  Different packaging options available.  See Alternatives

IN STOCK: 46,217

Can Ship immediately

Manufacturer Stock: 48,491   can ship 5/18/26

Minimum Order Quantity: 20

Factory Lead-Time 2 Weeks can ship 5/18/26

Price (USD)

Qty
Unit Price
20
$2.484
25
$2.398
100
$2.226
250
$1.949
500
$1.709
1,050
$1.234
2,550
$1.156
5,100 +
$0.974
Log in for special pricing Click for Quote Price Match Request
