276AXXH-24D by schneider electric-legacy relays

276AXXH-24D

Schneider Electric-Legacy Relays

Power relay - SE Relays - SPST-NO - 10A - 24 VDC - epoxy sealed ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MAGNECRAFT / SCHNEIDER ELECTRIC 276AXXH-24D is an electromechanical relay designed for power applications. This relay operates at 24VDC with a contact resistance of 2.88KOhm and a maximum current rating of 10A. It features a single-pole, single-throw normally open configuration and has a compact size of 20.5x12.7x10mm, making it suitable for through-hole mounting. This reliable and durable THT power relay is ideal for various industrial and commercial electrical applications.

Search Keywords: 276AXXH24D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
276AXXH-24D
RoHS:
Yes
HTS:
8536410050
COO:
IN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
10 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
2.88 KOhm

IN STOCK: 186

Can Ship immediately

Minimum Order: 10

Multiple: 10

Factory Lead-Time 16 Weeks

Price (CAD)

Qty
Unit Price
10
$24.700
30
$24.088
50
$22.602
100
$20.551
250
$20.444
500
$19.739
1,000 +
$19.632
Suppliers Standard Package
Log in for special pricing
Click for Quote
