300XBXC1-120A by schneider electric-legacy relays

300XBXC1-120A

Schneider Electric-Legacy Relays

Power Relay - DPDT - side flange cover - quick connections terminals - 30A - 120V AC - 2NO + 2NC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Magnecraft / Schneider Electric part 300XBXC1-120A is a versatile electromechanical relay designed for various applications. It operates on a voltage of 110/120VAC and has a resistance of 1.27KOhm. With a double-pole double-throw (DPDT) configuration, this power relay can handle a current of up to 30A. Featuring a compact design, the relay has a flange for secure mounting and measures approximately 38.89x35.72x73.06mm. This makes it suitable for installations where space is limited. Reliable and efficient, the 300XBXC1-120A is a high-quality relay that can be used in a wide range of electrical control systems, industrial equipment, and automation applications.

Search Keywords: 300XBXC1120A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
300XBXC1-120A
RoHS:
Yes
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
110,120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
30 A
Mounting:
Flange Mount
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C

IN STOCK: 1,157

Ships today, if you order in

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
1
$64.759
5
$59.951
30
$56.872
50
$55.939
100
$50.793
250
$50.533
500 +
$50.288
