750XBXRC-12D by schneider electric-legacy relays
Image is representational - see mfr. specs

750XBXRC-12D

Schneider Electric-Legacy Relays

The 750XBXRC-12D is a DPDT plug-in electromechanical relay featuring a 12 VDC coil and a 10 A contact rating. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued & Replaced
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 750XBXRC-12D is a general-purpose, plug-in electromechanical relay designed for various switching applications. It features a DPDT (2 NC + 2 NO) contact configuration with silver alloy, gold-flashed contacts. The relay operates on a 12 VDC control voltage, has a coil resistance of 120 Ohms, and consumes an average of 1.4 W. It is rated to switch up to 10 A at 277 VAC or 30 VDC. Housed in a clear cover with a flag indicator and connecting via an 8-pin octal terminal, it is well-suited for industrial control panels and automation systems where easy installation and status verification are beneficial.

Search Keywords: 750XBXRC12D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
750XBXRC-12D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
16 A
Mounting:
Socket
Termination Style:
8-Pin Circular Plug
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 55 °C
Coil Resistance:
120 Ohm
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

IN STOCK: 160

Can Ship immediately

Minimum Order Quantity: 10

Multiple: 10

Price (USD)

Qty
Unit Price
10
$40.45
30
$39.95
50
$39.76
100
$39.55
250
$39.36
500
$39.16
1,000 +
$38.96
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Older Equivalent
W250CPX-6
W250CPX-6
VIEW PRODUCT
