66L060 by sensata / airpax
Image is representational - see manufacturer specifications
Sensata / AIRPAX Authorized Distributor

66L060

Bimetal Disc Thermostat Automotive - 8 lead Mini-DIP package w/4 leads ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Certificate of Compliance

DESCRIPTION

66L060 is a subminiature bimetallic disc thermostat in an 8-pin DIP package designed for accurate and reliable temperature sensing and switching on printed circuit boards. This single pole/single throw device features open on rise (limit) operation with a factory-preset operating temperature of 60°C (±5°C tolerance), gold-plated contacts, and positive snap action. The thermostat offers contact ratings up to 1A at 120VAC or 48VDC with up to 30,000 life cycles, and achieves 100,000 cycles at low-level gold contact switching. It is sealed with high-temperature epoxy to withstand wave soldering and board washing operations. Common applications include computers, computer peripherals, aircraft, automotive, and test equipment for thermal protection and alarm functions.

Search Keywords: 66L060

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
66L060
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
903210009
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
Tube
Close Temperature (Celsius):
40 °C
Close Temperature (Fahrenheit):
104 °F
Maximum Current Rating:
1 A
Maximum AC Voltage Rating:
120 V
Maximum DC Voltage Rating:
48 V
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.C.
Operating Temperature:
40°C to 130 °C
Set Point Function:
Open on Rise
Open Temperature (Celsius):
60 °C
Open Temperature (Fahrenheit):
140 °F

IN STOCK: 924

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$18.86
10
$14.94
25
$13.05
50
$12.21
75
$11.82
100 +
$11.70
