67L045

The 67L045 is a single-pole, single-throw (SPST) bimetal disc thermostat in a TO-220 package, configured to open on a temperature rise at a nominal 45°C. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 67L045 is a subminiature, snap-action bimetal disc thermostat designed for accurate temperature sensing and switching. As an 'L' type limit switch, it opens its contacts on a temperature rise at a nominal operating temperature of 45°C with a ±5°C tolerance. This device features a minimum temperature differential of 4°C and a minimum reset temperature of 20°C. It is rated for up to 0.5 amps at 48 VDC for 20,000 cycles, with a gold contact option for low-level switching down to 0.001A at 5 VDC for 100,000 cycles. Housed in a TO-220 package suitable for automated PCB assembly, the 67L045 is ideal for thermal management on crowded boards in power supplies, computers, and test equipment.

Search Keywords: 67L045

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
67L045
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
903210009
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Package Type:
Tube
Close Temperature (Celsius):
20 °C
Close Temperature (Fahrenheit):
68 °F
Maximum Current Rating:
1 A
Maximum AC Voltage Rating:
120 V
Maximum DC Voltage Rating:
48 V
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.C.
Operating Temperature:
40°C to 130 °C
Set Point Function:
Open on Rise
Open Temperature (Celsius):
45 °C
Open Temperature (Fahrenheit):
113 °F

IN STOCK: 0

On Order: 1,000   can ship 1/18/27

Minimum Order Quantity: 5

Factory Lead-Time 11 Weeks

Price (USD)

Qty
Unit Price
5
$7.30
25
$5.71
50
$4.93
100
$4.47
250
$4.38
500
$4.34
1,000 +
$4.31
