IUGN6-1-63F-20.0 by sensata / airpax
Image is representational - see manufacturer specifications

IUGN6-1-63F-20.0

Sensata / AIRPAX

Circuit Breaker Hydraulic Magnetic 1Pole 20A 277VAC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

IUGN6-1-63F-20.0 is a hydraulic magnetic circuit protector from the Airpax IAG/IUG series designed for reliable circuit protection and power switching in international equipment. This six-pole unit features a 63F delay characteristic (long delay with inertial feature providing approximately 12 times rated current inrush pulse tolerance) and is rated for 20.0 amperes at AC 50/60 Hz operation. The device incorporates screw or push-on terminal configurations with standard dimensions of 1.530 inches (38.86 mm) length and 2.52 inches (64.00 mm) maximum overall height, and operates with DC resistance of 0.006 ohms and AC impedance of 0.006 ohms at rated current. It is UL Recognized as a supplementary protector per UL STD. 1077 and CSA Certified, making it suitable for sensitive circuitry and automation systems requiring accurate circuit control with compact packaging.

Search Keywords: IUGN6163F200

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
IUGN6-1-63F-20.0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536200020
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3

IN STOCK: 4

Can Ship immediately

Minimum Order Quantity: 3

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
3
$78.61
6
$75.54
12
$74.60
21
$57.37
51
$41.85
102 +
$37.90
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
