IUGN6-1-72-30.0 by sensata / airpax
Image is representational - see manufacturer specifications
Sensata / AIRPAX Authorized Distributor

IUGN6-1-72-30.0

The IUGN6-1-72-30.0 is a single-pole, series trip hydraulic-magnetic circuit protector with a sealed toggle, rated for 30.0A with a long delay for DC/60Hz applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The IUGN6-1-72-30.0 is a single-pole, sealed toggle hydraulic-magnetic circuit protector designed for reliable overcurrent protection and power switching. This protector features a series trip configuration with screw terminals, a 30.0A current rating, and a long time delay (Curve 72) for DC or 60Hz circuits. It incorporates a trip-free mechanism that ensures the circuit opens during an overload regardless of the handle position and operates reliably in ambient temperatures from -40°C to +85°C. The sealed toggle design with bushing mounting ensures panel integrity, making it ideal for use in harsh environments such as military applications, data processing equipment, and medical instrumentation.

Search Keywords: IUGN6172300

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
IUGN6-1-72-30.0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536200020
COO:
MY
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
3
Type:
Hydraulic Magnetic
Voltage Rating:
240,80 VAC|VDC
Number of Poles:
1
Current Rating:
30 A
Terminal Design:
Screw
Operating Temperature:
-40 to 85 °C
Mounting:
Screw Mount

IN STOCK: 21

Ships today, if you order in

Minimum Order Quantity: 3

Multiple: 3

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
3
$96.56
6
$71.17
12
$66.01
21
$65.14
51
$39.44
102 +
$34.47
Supplier's Standard Package
