R11-1-15.0A-9641-1 by sensata / airpax
Image is representational - see manufacturer specifications
Sensata / AIRPAX Authorized Distributor

R11-1-15.0A-9641-1

SNAPAK® series is a snap-acting hydraulic magnetic circuit protector, rocker ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The R11-1-15.0A-9641-1 is a SNAPAK® Series hydraulic-magnetic circuit protector featuring a rocker handle actuator and single-pole configuration rated for 15.0A. This snap-acting device combines the functions of a power switch, fuse, and fuse holder into a single compact package, reducing assembly requirements and inventory needs. The unit features a panel cutout center distance of 0.805 inches [20.45 mm] and is designed for reliable, accurate circuit protection with safe, sure operation. The rocker handle provides intuitive ON/OFF control with a 15° toggle angle, and the device is engineered for integration into control panels and electrical systems requiring dependable overcurrent protection and switching functionality.

Search Keywords: R111150A96411

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
R11-1-15.0A-9641-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536200020
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
3

IN STOCK: 34

Can Ship immediately

Minimum Order Quantity: 3

Multiple: 3

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
3
$24.61
6
$22.09
12
$21.44
27
$18.33
51
$17.36
102
$16.52
252 +
$15.41
Supplier's Standard Package
Log in for special pricing
