T29-7721-1 by sensata / airpax
Image is representational - see manufacturer specifications
Sensata / AIRPAX Authorized Distributor

T29-7721-1

SNAPAK® series is a snap-acting hydraulicmagnetic circuit protector, paddle handle. ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

T29-7721-1 is a single-pole hydraulic-magnetic circuit protector from the SNAPAK® series manufactured by Airpax, combining power switching, fuse functionality, and circuit protection in one integrated package. The device features a toggle paddle handle actuator available in six color options (blue, white, red, green, yellow, or black) with a 15° operating angle and snap-in front mounting design. Key technical specifications include a panel cutout diameter of 0.500 inches (12.7 mm) and mounting dimensions with tolerances of ±0.005 inches (0.13 mm) for precision panel installation. The single-pole configuration with one line connection simplifies assembly and reduces inventory requirements compared to traditional three-component solutions. This circuit protector is engineered for reliable operation in industrial and OEM applications where compact, integrated power switching and protection are required.

Search Keywords: T2977211

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
T29-7721-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536200020
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
3

IN STOCK: 9

Can Ship immediately

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$57.92
6
$51.75
12
$50.18
27
$43.06
51
$40.62
102
$38.76
252 +
$35.96
Log in for special pricing
