10LPCV2425

Name: 10LPCV2425
Brand: Sensata Crydom
SKU: 45157455
Price: 1644.13 USD
Availability: InStock

SOLID STATE RELAY 48-660 V - Lin.Prop.Contr. 300Vac/25A 0-10Vdc ...

View Datasheet

Ask the Datasheet

RoHS Compliant

EACH Packaging

DESCRIPTION

The 10LPCV2425 is a linear proportional controller designed for precise control of 240 VAC resistive loads with a maximum output current of 25A. It features a 0-10 VDC control input with a control range of -1.0 to 20 VDC and a turn-on threshold of 0.5 VDC, providing smooth proportional power modulation across the full load range. The device operates with an input impedance of 25 kO and requires a sync voltage of 16-24 VAC from an external power supply module (PS120 or PS240). With an operating voltage range of 20-300 Vrms at 60Hz, a maximum off-state leakage current of 10 mArms, and a minimum load current of 0.10 Arms, the controller delivers reliable performance in industrial heating and temperature control applications. The unit is housed in thermally conductive epoxy encapsulation with a thermal resistance of 1.02°C/W, operates across an ambient temperature range of -30 to 80°C, and is ideal for infrared heaters, quartz heaters, thermal forming equipment, and conveyor speed control systems.

Product Highlights:

Potential Applications:

Search Keywords: 10LPCV2425

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Sensata / Crydom

Part No:

10LPCV2425

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536490080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
