CKM0620 by sensata / crydom
Image is representational - see manufacturer specifications
Sensata / Crydom Authorized Distributor

CKM0620

Solis-State Relay - Control Voltage 4-32 VDC - Max Input Current 9-11 mA - LED Green Input Status - Output 0-60 VDC - Max Load Current 20 A - Din Rail - 4 Pins ...

View Datasheet Ask the Datasheet
RoHS Compliant
EACH Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The CKM0620 is a solid-state relay with low leakage MOSFET output. Input control voltage range is 4-32 DC. Operating voltage is 0-60 VDC and the max load current is 20 ADC. Max wire size is #10 AWG (3mm). I/O isolation voltage is 2500 Vrms. Mounting type: din rail, screw.

Search Keywords: CKM0620

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
CKM0620
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410060
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
EACH
Output Type:
DC
Maximum Output Voltage:
60 V
Maximum Output Current:
20 A
Output Device:
N/A
Input Type:
DC
Input Voltage:
32 V
Mounting:
Din-Rail, Screw
Circuit Arrangement:
N/A
Dimension:
81.3 x 22.5 x 81.9 mm

IN STOCK: 40

Ships today, if you order in

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$158.39
5
$152.29
10
$145.53
20
$145.16
50
$144.80
100 +
$144.44
Supplier's Standard Package
