DRA1-MPDCD3 by sensata / crydom

DRA1-MPDCD3

Sensata / Crydom

DRA1 MP Series -10mm Single Channel DIN Rail Mount SSR Assembly - Control Voltage 3-32 VDC - Typical Input Current 2.6 mADC - Output 3-60 VDC - Max Load Current 3 ADC - LED Status Indicator - N.O. DC Output

Datasheet
RoHS Compliant
EACH Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DRA1-MPDCD3 is a 10 mm single channel DIN rail mount solid-state relay assembly with led status indicator. Input control voltage range is 3-32 VDC. Operating voltage is 3-60 VDC and the max load current is 3 ADC. I/O isolation voltage is 4000 Vrms.

Search Keywords: DRA1MPDCD3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
DRA1-MPDCD3
RoHS:
Yes
HTS:
8536410060
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
EACH
Output Type:
DC
Maximum Output Voltage:
60 V
Maximum Output Current:
3 A
Output Device:
N/A
Input Type:
DC
Input Voltage:
32 V
Mounting:
DIN Rail
Circuit Arrangement:
1 Form A
Dimension:
89.6 x 10 x 62.2 mm

IN STOCK: 178

Ships today, if you order in

On Order: 600   can ship 1/1/26

Factory Lead-Time 23 Weeks

Price (CAD)

Qty
Unit Price
1
$118.447
5
$112.519
10
$106.900
30
$101.525
50
$96.472
100
$91.649
250 +
$87.070
