MINT1150A2406K01 by sl power / advanced energy

Image is representational - see mfr. specs

MINT1150A2406K01

The MINT1150A2406K01 is a 150W single-output AC/DC power supply providing a 24V output, designed for medical applications in a compact 2" x 4" package. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The MINT1150A2406K01 is a 150W medical-grade AC/DC power supply that delivers a regulated 24V output. It operates over a universal input range of 90-264 VAC and provides an output current of 6.25A with 200LFM airflow or 4.17A with convection cooling. Housed in a compact 2" x 4" x 1.3" package suitable for 1U applications, it features 2 x MOPP input-to-output isolation and is approved to CSA/EN/IEC/UL60601-1, 3rd Edition standards. The unit includes Power Fail and DC OK signals, along with overvoltage and short circuit protection for enhanced reliability. Its high power density, wide operating temperature range, and medical certifications make it ideal for portable medical devices and other space-constrained applications.

Product Highlights:

Potential Applications:

Search Keywords: MINT1150A2406K01

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

SL Power / Advanced Energy

Part No:

MINT1150A2406K01

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504409520

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
