TE20A1203F01 by sl power / advanced energy
Image is representational - see manufacturer specifications
SL Power / Advanced Energy Authorized Distributor

TE20A1203F01

Plug-In Adapter Single-OUT 12V 1.5A 18W ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

TE20A1203F01 is an 18W single-output external AC-DC power supply designed for test and measurement and industrial applications. It delivers 12.0V output at 1.50A maximum current with 120mV peak-to-peak ripple and noise, meeting DoE Efficiency Level VI requirements and heavy industrial EMC standards. The unit features universal input of 90-264Vac, ±1% line regulation, ±5% load regulation, and operates over -20°C to +70°C ambient temperature range. It includes comprehensive protection features including overtemperature shutdown with auto-recovery, overload protection in hiccup mode, and short-circuit protection, with input-output isolation of 4000Vac. The power supply is approved to EN/IEC/UL 60950-1 2nd Edition Amendment 2, offers greater than 1,000,000 hours MTBF, and includes a 3-year warranty, making it suitable for demanding industrial and test equipment applications.

Search Keywords: TE20A1203F01

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
SL Power / Advanced Energy
Part No:
TE20A1203F01
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409510
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
250
Adapter Color:
Black
Dimension:
84 x 47 x 31 mm

IN STOCK: 312

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$15.76
10
$15.39
25
$15.15
50
$14.94
100
$14.53
250
$14.35
500 +
$14.26
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
