896H-1CH-D1-12VDC by song chuan

896H-1CH-D1-12VDC

Song Chuan

Power Relay 12VDC 50(NO)/30(NC)A SPDT(31.3x25.8)mm Socket Automotive ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SONG CHUAN 896H-1CH-D1-12VDC is a high-quality power relay designed for automotive applications. It is a 12VDC relay with a rugged construction and features a SPDT (single-pole double-throw) configuration. The relay has a 50A normally open (NO) contact rating and a 30A normally closed (NC) contact rating, making it suitable for various electrical systems in vehicles. With its compact size of 31.3x25.8mm, the relay can easily fit into standard automotive relay sockets. It is a reliable and durable choice for any automotive power control applications.

Search Keywords: 896H1CHD112VDC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Song Chuan
Part No:
896H-1CH-D1-12VDC
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5200
Contact Form:
1 Form C
Relay Construction:
Non-Latching
Coil Current:
133 mA
Coil Resistance:
90 Ohm
Contact Material:
Silver Tin Oxide
Operate Time:
20 ms
Seal:
Unsealed
Mounting:
Socket
Termination Style:
Quick Connect
Operating Temperature:
-40 to 125 °C

IN STOCK: 3,305

Can Ship immediately

Minimum Order: 10

Factory Lead-Time 30 Weeks

Price (CAD)

Qty
Unit Price
10
$7.029
100
$4.334
250
$3.981
500
$3.813
1,000
$3.675
2,500
$3.629
5,200
$3.614
10,400 +
$3.599
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
