SW-424
StancorPower Transformer - Pri:115V - Sec:24/12 V - 2500Vrms - 6VA - 6 Terminals - PC Pin Thru-Hole.
RoHS Compliant
Certificate of Compliance Guarantee
DESCRIPTION
The SW-424 is split bobbin PCB mount transformer designed to eliminates electrostatic shielding requirement and expense. Dimension of this transformer are 41.4 x 33.27 x 33.27 mm.
Search Keywords: SW424
SPECIFICATIONS
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Stancor
Part No:
SW-424
RoHS:
Yes
HTS:
8504314035
COO:
TW
Supplier Standard Pack:
100
Primary Configuration:
Single
Primary Side Voltage:
115 V
Secondary Configuration:
Dual
Secondary Side Voltage:
24,12 V
Secondary Side Current:
250,500 mA
Power Rating:
6 VA
Mounting:
Through Hole
Dimension:
41.4 x 33.27 x 33.27 mm
IN STOCK: 239
Ships today, if you order in
MOQ for out of Stock Qty: 25
Factory Lead-Time 9 Weeks
Price (CAD)
Qty
Unit Price
1
$52.217
5
$36.858
10
$34.639
25
$31.851
50
$31.163
75
$30.181
100
+
$30.028
Datasheet
