MK15-B-2

Standex Electronics

The MK15-B-2 is a magnetically operated reed proximity switch in a compact package designed for surface mount (SMD) applications. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MK15-B-2 is a magnetically operated reed proximity switch featuring flat, bent SMD leads for surface mounting. It has a magnetic sensitivity class 'B', corresponding to a pull-in range of 10-15 Ampere-Turns (AT). This switch is rated for a maximum switching power of 10 W, a switching voltage of 200 V, and a switching current of 0.5 A. Housed in a compact 19.5 x 2.5 x 2.5 mm package, it operates over a wide temperature range from -40°C to +130°C. Common applications include telecommunication hook switches, microphone switching elements, and other space-constrained electronic PCBs where components are surface-mounted.

Search Keywords: MK15B2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Standex Electronics
Part No:
MK15-B-2
Alias/AKA:
9151710022
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410060
COO:
JP
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2500
Package Type:
REEL
Switch Configuration:
N.O.
Device Sensitivity Range:
10 to 15 AT
Mounting:
PCB Surface Mount
Maximum AC Voltage Rating:
200 V
Maximum DC Voltage Rating:
200 V
Maximum Current Rating:
1.25 A
Operating Temperature:
-40 to 130 °C
Terminal Type:
Gull Wing
Dimension:
16 x 2.5 x 2.5 mm
Glass Length:
N/R

IN STOCK: 0

On Order: 5,000   can ship 5/13/26

Minimum Order Quantity: 500

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
500
$0.6569
1,000
$0.6159
2,500
$0.5750
5,000
$0.5480
7,500
$0.5335
10,000
$0.5253
15,000
$0.5106
25,000 +
$0.5055
Reel Package
