1SNK506152R0000

Products found: 0

Supplier:

TE Connectivity / ABB Entrelec

Part No:

1SNK506152R0000

RoHS:

Yes

HTS:

8536904000

COO:

MA

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

25

Package Type:

Box

Impulse Withstanding Voltage Rating (IEC):

8000 V

Rated Cross Section:

10 AWG, 4 mm²

Product Weight:

19.4 g, .764 oz

Product Depth:

48.3 mm

Main Circuit Capacity - 1 Rigid Conductor per Screw Clamp:

24 – 10 AWG, .2 – 6 mm²

Main Circuit Capacity - Twin Ferrule per Screw Clamp:

24 – 14 AWG, .22 – 2.5 mm²

Product Length:

48.3 mm

UL Flammability Rating:

UL 94V-0

Installation Temperature Range:

-5 – 40 °C, 23 – 104 °F

Dielectric Test Voltage:

2000 V

IP Rating:

IP20

Modular Terminal Block Product Type:

Screw Clamp Terminal Block

Tool Size:

.157 in, 4 mm

Number of Circuits:

1

Short-Time Withstanding Current Rating @ 1s:

480 A

Product Height:

79.2 mm

Main Circuit Capacity - 2 Rigid Conductors per Screw Clamp:

24 – 14 AWG, .2 – 2.5 mm²

Product Spacing:

.236 in, 6 mm

Housing Material:

Polyamide

Number of Levels:

1

Connector Mounting Type:

DIN Rail

Gauge Type:

A4-B3

Wire Stripping Length:

.413 in, 10.5 mm

Block Configuration:

Ground

Number of Positions:

4

Main Circuit Capacity - 1 Insulated Ferrule per Screw Clamp:

24 – 12 AWG, .22 – 4 mm²

Storage Temperature Range:

-55 – 110 °C, -67 – 230 °F

Main Circuit Capacity - 1 Flexible Conductor per Screw Clamp:

.22 – 6 mm²

Operating Temperature Range:

-55 – 110 °C, -67 – 230 °F

DIN Rail Mounting Type:

TH35-15 , TH35-7.5

Primary Product Color:

Green & Yellow
