1SNK705010R0000

Products found: 0

Supplier:

TE Connectivity / ABB Entrelec

Part No:

1SNK705010R0000

RoHS:

Yes

HTS:

8536904000

COO:

MA

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

50

Package Type:

Box

Number of Levels:

1

Impulse Withstanding Voltage Rating (IEC):

8000 V

Tool Size:

.138 in, 3.5 mm

Product Depth:

40.2 mm

Product Weight:

5.5 g, .217 oz

Power Loss:

.8 W

Number of Positions:

2

Modular Terminal Block Product Type:

PI-Spring Terminal Block

Number of Circuits:

1

Storage Temperature Range:

-55 – 110 °C, -67 – 230 °F

Block Configuration:

Feed-Through

Operating Voltage Rating (UL & CSA) (Max) - Main Circuit:

600 V

Main Circuit Capacity - 1 Rigid Conductor per Spring Clamp:

26 – 12 AWG, .2 – 4 mm²

UL Flammability Rating:

UL 94V-0

Product Height:

50.9 mm

Voltage Rating (IEC):

1000 V

Current Rating (CSA):

20 A

DIN Rail Mounting Type:

TH35-15 , TH35-7.5

Connector Mounting Type:

DIN Rail

Gauge Type:

A2 / 2.3 mm Dia.

Housing Color:

Gray

Product Length:

40.2 mm

Product Spacing:

.205 in, 5.2 mm

Main Circuit Capacity - Twin Ferrule per Spring Clamp:

26 – 20 AWG, .22 – .5 mm²

Rated Cross Section:

12 AWG, 2.5 mm²

Operating Temperature Range:

-55 – 110 °C, -67 – 230 °F

Installation Temperature Range:

-5 – 40 °C, 23 – 104 °F

Short-Time Withstanding Current Rating @ 1s:

300 A

Dielectric Test Voltage:

2200 V

Main Circuit Capacity - 1 Insulated Ferrule per Spring Clamp:

26 – 14 AWG, .22 – 2.5 mm²

Housing Material:

Polyamide

IP Rating:

IP20

Current Rating (IEC):

24 A

Voltage Rating (CSA):

600 V

Current Rating (UL):

20 A

Wire Stripping Length:

.433 in, 11 mm
