1SNK706152R0000

Products found: 0

Supplier:

TE Connectivity / ABB Entrelec

Part No:

1SNK706152R0000

RoHS:

Yes

HTS:

8536904000

COO:

MA

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

20

Package Type:

Box

IP Rating:

IP20

Short-Time Withstanding Current Rating @ 1s:

480 A

Main Circuit Capacity - 1 Insulated Ferrule per Spring Clamp:

26 – 12 AWG, .5 – 4 mm²

Main Circuit Capacity - Twin Ferrule per Spring Clamp:

26 – 18 AWG

Connector Mounting Type:

DIN Rail

Rated Cross Section:

10 AWG, 4 mm²

Product Spacing:

.236 in, 6 mm

Installation Temperature Range:

-5 – 40 °C, 23 – 104 °F

Housing Material:

Polyamide

Main Circuit Capacity - 1 Rigid Conductor per Spring Clamp:

26 – 10 AWG, .5 – 6 mm²

UL Flammability Rating:

UL 94V-0

Gauge Type:

2.9 mm Dia.

Modular Terminal Block Product Type:

PI-Spring Terminal Block

Product Depth:

41.2 mm

Operating Temperature Range:

-55 – 110 °C, -67 – 230 °F

Product Weight:

18.4 g, .724 oz

Number of Levels:

1

Storage Temperature Range:

-55 – 110 °C, -67 – 230 °F

Wire Stripping Length:

.492 in, 12.5 mm

Dielectric Test Voltage:

2200 V

Product Length:

41.2 mm

Product Height:

96.2 mm

DIN Rail Mounting Type:

TH35-15 , TH35-7.5

Impulse Withstanding Voltage Rating (IEC):

8000 V

Number of Positions:

4

Tool Size:

.138 in, 3.5 mm

Block Configuration:

Ground

Number of Circuits:

1

Primary Product Color:

Green & Yellow
