7022AKT by te connectivity / agastat brand
Image is representational - see mfr. specs

7022AKT

TE Connectivity / Agastat Brand

Industrial Electropneumatic Timing Relay - 2FormC - DPDT - 1 to 300 sec Off Delay - 120VAC 60 Hz / 110VAC 50Hz - Aux Switch - 2 Step Timing ...

Datasheet
RoHS Non-Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

7022AKT is an industrial electropneumatic off-delay (delay on drop-out) timing relay from the AGASTAT 7000 series. It features a 2-pole DPDT (2 form C) contact arrangement with a linear timing range of 1 to 300 seconds (code K). The relay operates with 120VAC at 60Hz coil voltage (code A) with an operating voltage range of 102-132VAC, and includes a transient suppressor option (T). Key specifications include ±5% repeat accuracy for delays of 200 seconds or less, 50 msec relay operate time, 500 megohm insulation resistance, and approximately 8 watts power consumption. The unit operates within a temperature range of -20°F to +165°F (-29°C to 74°C) and weighs approximately 2 lbs 4 oz, making it suitable for industrial control applications requiring precise off-delay timing functions.

Product Highlights:

  • 7000 Electropneumatic Timing Series
  • Time Delay Relay
  • Input Voltage = 110 VAC, 120 VAC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Rating = 10A @ 240 VAC

Search Keywords: 7022AKT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Agastat Brand
Part No:
7022AKT
Alias/AKA:
1-1423162-9
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536410050
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Panel Mount
Type:
Time Delay Relay
Contact Arrangement:
DPDT
DC Coil Voltage:
N/A
AC Coil Voltage:
115 V
Contact Form:
2 Form C
Maximum Current Rating:
10 A
Termination Style:
Screw Terminal
Time Range:
1 to 300 sec

IN STOCK: 8

Can Ship immediately

MOQ for out of Stock Qty: 2

Factory Lead-Time 35 Weeks

Price (USD)

Qty
Unit Price
1
$960.98
2
$921.42
4
$912.29
6
$903.26
8 +
$894.32
