7022BKX by te connectivity / agastat brand

7022BKX

TE Connectivity / Agastat Brand

Industrial Electropneumatic Timing Relay - 2FormC - DPDT - 1 to 300 sec Off Delay - 240VAC 60 Hz / 220VAC 50Hz - Panel Mount ...

Datasheet
RoHS Non-Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity Agastat 7022BKX is a high-quality industrial electropneumatic timing relay designed for precision timing applications. This versatile relay features a 2FormC DPDT configuration and a 1 to 300 second off delay to suit a variety of timing requirements. Operating on 240VAC 60 Hz or 220VAC 50Hz power sources, this relay is ideal for panel mounting in industrial settings where reliability and accuracy are critical. Trust the TE Connectivity Agastat brand for top-notch performance and durability in your timing applications.

Product Highlights:

  • 7000 Electropneumatic Timing Series
  • Time Delay Relay
  • Input Voltage = 220 VAC, 240 VAC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Rating = 10A @ 240 VAC

Search Keywords: 7022BKX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Agastat Brand
Part No:
7022BKX
RoHS:
No
HTS:
8536410050
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Panel Mount
Type:
Time Delay Relay
Contact Arrangement:
DPDT
DC Coil Voltage:
N/A
AC Coil Voltage:
230 V
Contact Form:
2 Form C
Maximum Current Rating:
10 A
Termination Style:
Screw Terminal
Time Range:
1 to 300 sec

IN STOCK: 0

On Order: 12   can ship 12/29/25

MOQ for out of Stock Qty: 4

Factory Lead-Time 62 Weeks

Price (CAD)

Qty
Unit Price
1
$1,042.403
4
$999.495
8
$989.588
12
$979.804
16 +
$970.094
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
