VTM7ACD by te connectivity / agastat brand
Image is representational - see manufacturer specifications
TE Connectivity / Agastat Brand Authorized Distributor

VTM7ACD

Time Delay Relay 120VDC 120VAC SPST-NO( (50.8mm 50.8mm 22.5mm)) Panel Medical ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

VTM7ACD is a repeat cycle timing module designed for industrial electropneumatic control systems. It features independently adjustable on and off times with reliable solid state timing circuitry and excellent transient protection. The module operates with 12 VDC input voltage and provides 1 amp load capacity, with timing ranges of 0.5 to 10 seconds or 3 to 60 minutes depending on configuration. The compact design incorporates flame retardant, solvent resistant housing and utilizes external resistor adjustment for precise time delay control. This module is ideal for applications requiring repetitive cycle timing in industrial automation, process control, and equipment sequencing where reliable, adjustable timing intervals are essential.

Product Highlights:

  • VTM7 Series
  • Time Delay Relay
  • Input Voltage = 120 VAC
  • Input Voltage = 120 VDC
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O Solid State

Search Keywords: VTM7ACD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Agastat Brand
Part No:
VTM7ACD
Alias/AKA:
1437482-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Panel Mount14823
Contact Arrangement:
SPST-NO14812
DC Coil Voltage:
120 V
AC Coil Voltage:
120 V
Contact Form:
1 Form A14813
Termination Style:
Quick Connect14831
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 20

Ships today, if you order in

Price (USD)

Qty
Unit Price
1
$130.41
3
$128.00
6
$125.58
11
$123.17
50 +
$120.76
Log in for special pricing Click for Quote Price Match Request
