ADE0204 by te connectivity / alcoswitch brand

ADE0204

TE Connectivity / Alcoswitch Brand

Switch DIP OFF ON SPST 2 Raised Slide 0.1A 24VDC PC Pins 2.54mm Thru-Hole Tube ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ADE0204 is a versatile DIP switch from TE Connectivity's Alcoswitch Brand that is designed for various applications. This SPST (Single Pole Single Throw) switch features a durable construction with 2 raised slides, ensuring easy and reliable operation. With a maximum current rating of 0.1A and a voltage rating of 24VDC, it can handle a wide range of electrical loads. The switch is designed for easy installation with PC pins and a 2.54mm pitch, making it compatible with standard PCB mounting. It is supplied in a convenient tube packaging, ensuring secure storage and transportation.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Through Hole
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Extended, Slide
  • Not Sealed

Search Keywords: ADE0204

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADE0204
RoHS:
Yes
HTS:
8536509032
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
Tube
Body Orientation:
Straight
Actuator Style:
Raised Slide
Actuator Length:
1 mm
Number of Positions:
2
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@24VDC A
Contact Plating:
Gold Flash/Nickel
Terminal Pitch:
2.54 mm

IN STOCK: 14,505

Can Ship immediately

Minimum Order: 60

Multiple: 60

Factory Lead-Time 17 Weeks

Price (CAD)

Qty
Unit Price
60
$0.954
300
$0.587
540
$0.568
1,020
$0.551
2,520
$0.548
5,040
$0.545
7,500
$0.543
10,020 +
$0.540
