ADF08STTR04 by te connectivity / alcoswitch brand

ADF08STTR04

TE Connectivity / Alcoswitch Brand

Switch DIP OFF ON SPST 8 Flush Slide 0.1A 24VDC Gull Wing 2.54mm SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / Alcoswitch Brand part ADF08STTR04 is a DIP switch with a SPST configuration designed for use in various electronic applications. It features a flush slide actuator with an OFF-ON setting and a current capacity of 0.1A at 24VDC. This surface-mount device (SMD) comes in a gull-wing packaging style with a pin spacing of 2.54mm and is supplied in tape and reel form for easy handling during production.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Surface Mount
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Flush, Slide
  • Sealed

Search Keywords: ADF08STTR04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADF08STTR04
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
750
Package Type:
Reel
Body Orientation:
Straight
Actuator Style:
Flush Slide
Actuator Length:
0 mm
Number of Positions:
8
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.1@24VDC A
Contact Plating:
Gold Flash
Terminal Pitch:
2.54 mm

IN STOCK: 12,746

Ships today, if you order in

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 1875

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
25
$1.451
500
$1.156
1,000
$1.127
1,875
$1.083
3,750
$1.021
5,625
$1.009
7,500 +
$0.988
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
