ADP0404 by te connectivity / alcoswitch brand

ADP0404

TE Connectivity / Alcoswitch Brand

Switch DIP OFF ON SPST 4 Piano 0.1A 24VDC 0.4VA PC Pins 2.54mm Thru-Hole ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / Alcoswitch Brand part ADP0404 is a high-quality DIP switch designed for various electronic applications. With a compact size and sturdy construction, this switch features a SPST configuration and is capable of handling a current of up to 0.1A and a voltage of 24VDC, making it suitable for a wide range of circuits. The switch also has a low power consumption of 0.4VA, ensuring efficient operation. The PC pins with a 2.54mm pitch allow for easy and secure through-hole mounting, providing a reliable connection. Whether used in consumer electronics, industrial equipment, or other electronic devices, the ADP0404 switch guarantees reliable performance and precise control.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Through Hole
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Piano (Side Actuated)
  • Not Sealed

Search Keywords: ADP0404

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADP0404
RoHS:
Yes
HTS:
8536509032
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Pack
Body Orientation:
Straight
Actuator Style:
Piano
Actuator Length:
2.11 mm
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.4@20VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
2.54 mm
  Possible Replacement options available.  See Alternatives

IN STOCK: 189

Can Ship immediately

On Order: 5,250   can ship 2/18/26

Minimum Order: 35

Multiple: 35

Factory Lead-Time 19 Weeks
