ADPA0404 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

ADPA0404

TE Connectivity / Alcoswitch Brand

Switch DIP OFF ON SPST 4 Piano 0.1A 24VDC 0.4VA PC Pins 2.54mm Thru-Hole Tube ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

ADPA0404 is a 4-position DIP switch featuring a piano-style actuator with lever-up "on" configuration, designed for auto-insertable through-hole and surface mount applications. The switch utilizes a PPS-UL94V-0 base and cover with a PA6T-UL94V-0 white actuator, and incorporates copper alloy contacts with gold/nickel plating on the moving contact for reliable electrical performance. It operates across a temperature range of -30°C to +85°C, withstands solder heat resistance of 245°C ±5°C for 30 seconds, and supports a maximum switching rating of 100 mA at 24 VDC with a contact rating of 0.4 VA at 20 VDC. The switch features high-pressure wiping contacts allowing aqueous or solvent cleaning, gas-tight contacts, and an actuator travel of 1.30 mm at 25° with an operating force less than 800 grams and a life expectancy of 1,000 cycles. Common applications include industrial control panels, consumer electronics, and embedded systems requiring reliable configuration switching.

Product Highlights:

  • Switch - Mechanical
  • Switch Type = DIP
  • PCB Mount Style = Through Hole
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Piano (Side Actuated)

Search Keywords: ADPA0404

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADPA0404
Alias/AKA:
4-1571999-4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509032
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Pack
Body Orientation:
Straight
Actuator Style:
Piano
Actuator Length:
2.11 mm
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.4@20VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
2.54 mm

IN STOCK: 779

Can Ship immediately

MOQ for In Stock Qty: 70

MOQ for out of Stock Qty: 70

Multiple: 35

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
70
$2.59
250 +
$2.58
