AWTT1504 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

AWTT1504

TE Connectivity / Alcoswitch Brand

Switch Toggle ON OFF (ON) DPDT Round Lever Quick Conn 20A 250VAC 30VDC Panel Mount with Threads Bulk ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AWTT1504 is a 4-pole waterproof toggle switch featuring ON-OFF switching function with 0.250 inch quick connect terminals, rated for 20 A at 125/250 VAC and UL/CSA recognized for 20 A at 30 VDC. The switch incorporates brass silver alloy contacts for superior switching performance, with an electrical life of 20,000 cycles at full load and a maximum contact resistance of 10 mOhm. It features an IP67 panel mounting seal with a 12 mm threaded brass bushing with chrome plating, panel cut-out of 12.5 mm diameter, and operates reliably across a temperature range of -20°C to +70°C. The switch is ideal for industrial control applications, marine equipment, and other demanding environments where waterproof operation and high current switching capability are essential.

Search Keywords: AWTT1504

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
AWTT1504
Alias/AKA:
1-6437630-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Carton

IN STOCK: 39

Can Ship immediately

MOQ for out of Stock Qty: 125

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
1
$60.63
25
$51.77
50
$48.42
125
$47.33
250
$47.22
375
$47.09
500 +
$46.98
Log in for special pricing Click for Quote Price Match Request
