FSMRA7JH04 by te connectivity / alcoswitch brand
Image is representational - see manufacturer specifications
TE Connectivity / Alcoswitch Brand Authorized Distributor

FSMRA7JH04

Switch Tactile OFF (ON) SPST Round Button PC Pins 0.05A 24VDC 1.57N Thru-Hole Loose Piece ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity / Alcoswitch Brand part FSMRA7JH04 is a tactile switch with an OFF (ON) action. It features a single-pole, single-throw (SPST) configuration and is designed with a round button. With PC pins for easy circuit board mounting, this switch has a maximum rating of 0.05A and 24VDC. It provides a tactile feedback of 1.57N and is designed for through-hole installation. This particular variant is sold as a loose piece, offering flexibility in ordering quantities.

Search Keywords: FSMRA7JH04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
FSMRA7JH04
Alias/AKA:
2-1825027-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1000
Package Type:
BAG
Dimension:
8.41 x 10 x 7.01 mm
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
Off (On)
Actuator Style:
Round Button
Operating Force:
1.57 N
Contact Rating @ Voltage:
0.05@24VDC A
Illumination Type:
N/R
Body Orientation:
Right Angle
Termination Style:
PC Pins
Seal Location:
N/A

IN STOCK: 235,073

Ships today, if you order in

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 17 Weeks
