GDH04STR04 by te connectivity / alcoswitch brand

GDH04STR04

TE Connectivity / Alcoswitch Brand

Switch DIP ON OFF SPST 4 Recessed Rocker 0.025A 24VDC Gull Wing 1.27mm SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / Alcoswitch Brand part GDH04STR04 is a compact and reliable DIP switch. With a single pole, single throw configuration, it allows for convenient ON and OFF settings. The switch features four recessed rockers, making it easy to operate and reducing the risk of accidental activation. With a low current rating of 0.025A and a voltage rating of 24VDC, it is suitable for a wide range of applications. Designed for surface mount installation, it is compatible with a 1.27mm pitch and comes in tape and reel packaging for efficient use on automated assembly lines.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Surface Mount
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Recessed Rocker
  • Sealed

Search Keywords: GDH04STR04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
GDH04STR04
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
Reel
Body Orientation:
Straight
Actuator Style:
Recessed Rocker
Actuator Length:
0 mm
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.025@24VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
1.27 mm

IN STOCK: 28,123

Can Ship immediately

Minimum Order: 250

Factory Lead-Time 19 Weeks

Price (CAD)

Qty
Unit Price
250
$2.863
500
$2.725
2,000
$2.358
4,000
$2.312
6,000 +
$2.297
Suppliers Standard Package
