MGDH04STR04 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

MGDH04STR04

TE Connectivity / Alcoswitch Brand

Switch DIP OFF ON SPST 4 Recessed Slide 0.025A 24VDC Gull Wing 1.27mm SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MGDH04STR04 is a low profile DIP switch designed for surface mount applications with tape and reel packaging. This 4-position switch features a contact rating of 100 milliamps at 50 VDC (non-switching) and 25 milliamps at 24 VDC (switching), with an initial contact resistance of 100 milliohms maximum. The switch is constructed with PPS UL94V-0 rated case and cover materials, copper alloy contacts with gold over nickel plating, and includes a polyimide film tape seal. Operating temperature ranges from -30°C to +85°C with storage temperature from -45°C to +100°C. The component is RoHS compliant per EU Directive 2002/95/EC and is ideal for configuration settings in electronic devices requiring reliable, compact switching solutions.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Surface Mount
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Slide
  • Not Sealed

Search Keywords: MGDH04STR04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
MGDH04STR04
Alias/AKA:
1825140-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2000
Package Type:
Reel
Body Orientation:
Straight
Actuator Style:
Recessed Slide
Actuator Length:
0 mm
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.025@24VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
1.27 mm

IN STOCK: 3

Can Ship immediately

Buy all 3 in-stock or the regular minimum order quantity of 250

Stock lot only: 3

Minimum Order Quantity: 250

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
1
$1.439
250
$1.308
500
$1.288
2,000
$1.246
4,000
$1.236
6,000
$1.215
8,000
$1.205
10,000
$1.195
16,000 +
$1.185
Reel Package
