MSS2200G04 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

MSS2200G04

TE Connectivity / Alcoswitch Brand

Switch Slide DPDT Top Slide 20VAC 20VDC 0.4VA PC Pins Bracket Mount/PCB Through Hole Tray ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MSS2200G04 is a double pole double throw (DPDT) slide switch from the MSS Series designed for reliable low-level signal switching. It features a vertical through-hole mount configuration with a top-style black actuator and gold-plated contacts for enhanced conductivity. The switch is rated at 0.4 VA max at 20 VDC or peak AC, with a PCB tail length of 5.33 mm and actuator travel of 2.00 mm. The housing meets UL 94V-0 flammability rating and is RoHS/ELV compliant, supporting wave solder processes up to 265°C. This switch is ideal for applications requiring compact, reliable switching in consumer electronics and instrumentation.

Search Keywords: MSS2200G04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
MSS2200G04
Alias/AKA:
1825261-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
600
Package Type:
Pack
Mounting:
Bracket Mount/PCB Through Hole
Body Orientation:
Straight
Actuator Style:
Top Slide
Pole Throw Configuration:
DPDT
Switch Configuration:
N/A
Contact Rating @ Voltage:
0.4@20VAC 20VDC A
Contact Plating:
Gold/Nickel
Operating Temperature:
-20 to 85 °C
Termination Style:
PC Pins
Dimension:
14 x 5.8 x 12.3 mm

IN STOCK: 462

Can Ship immediately

On Order: 3,600   can ship 6/29/26

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 600

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
25
$2.11
100
$1.80
250
$1.66
600
$1.51
1,200
$1.24
1,800
$1.23
2,400 +
$1.15
Suppliers Standard Package
