TT13A3T04 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

TT13A3T04

TE Connectivity / Alcoswitch Brand

Switch Toggle ON None OFF SPST Long Baton Toggle Wire Lug 3A 125VAC 28VDC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TT13A3T04 is a single-pole single-throw (SPST) toggle switch from the TT Series (Tiny) manufactured by TE Connectivity/Alcoswitch. This switch features an "A" function action (On None Off) with a long actuator and wire lug terminals designed for reliable panel-mount installation. The switch has a 10-48 UNS-2A threaded mounting hole and oblong terminal holes measuring 0.040 inches wide by 0.080 inches long (1.00 mm × 2.00 mm). The actuator is flat-topped with a height of approximately 0.172 inches (4.37 mm) and a width of 0.236 inches (5.99 mm), providing ergonomic control. This switch is commonly used in industrial control panels, instrumentation, and equipment requiring simple on/off switching with a rated current capacity of 0.4 VA to 3 Amps, making it suitable for low to moderate power applications.

Search Keywords: TT13A3T04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
TT13A3T04
Alias/AKA:
1825223-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Pole Throw Configuration:
1P1T (SPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
3@125VAC 28VDC A
Actuator Style:
Long Baton Toggle
Mounting:
Panel Mount with Threads
Thread Size:
10-48
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
8.1 x 5.99 x 26.78 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 221

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 78 Weeks

Price (USD)

Qty
Unit Price
5
$14.16
10
$13.82
25
$13.61
50
$13.41
100
$13.05
250
$12.89
500 +
$12.05
