4PCR-08-006 by te connectivity / buchanan brand
Image is representational - see manufacturer specifications
TE Connectivity / Buchanan Brand Authorized Distributor

4PCR-08-006

Conn Barrier Strip 8 POS 8.26mm Solder RA Thru-Hole 20A/Contact Package ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

4PCR-08-006 is a right-angle printed circuit board mount barrier strip terminal block from the BUCHANAN Series #4 Tri-Barrier line. It features a 0.325" [8.26mm] pitch with #4-40 screw size spacing and wire clamp screw termination style. The terminal block is constructed with a thermoplastic polyamide housing rated UL94V-0 for flammability, with bright acid tin over copper alloy terminals. It supports a wire range of 12-22 AWG with electrical ratings of UL Class C 20 Amps at 150V and UL Class D 10 Amps at 300V, and operates up to 105°C maximum temperature. This RoHS compliant terminal block is ideal for PCB applications requiring secure wire connections in industrial and electronic equipment.

Product Highlights:

  • Barrier Strip
  • Barrier Style = Single Row, Tri-Barrier
  • Block Style = Open Bottom with Standoffs
  • 8.26 mm Centerline
  • Right Angle Mount Angle

Search Keywords: 4PCR08006

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Buchanan Brand
Part No:
4PCR-08-006
Alias/AKA:
3-1437648-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
150
Package Type:
BAG
Type:
Barrier Strip
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
8.26 mm
Number of Circuits:
8
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Wire Size:
12-22 AWG
Operating Temperature:
N/A

IN STOCK: 1,825

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 188

Factory Lead-Time 27 Weeks

Price (USD)

Qty
Unit Price
5
$17.30
50
$17.26
100
$17.22
188
$17.18
375
$9.12
563
$6.41
750 +
$6.28
Log in for special pricing Click for Quote Price Match Request
