NC6-P108-10 by te connectivity / buchanan brand
Image is representational - see manufacturer specifications
TE Connectivity / Buchanan Brand Authorized Distributor

NC6-P108-10

Barrier Block - 10 Circuits - 10 Entries - 0.375" (9.53mm) Pitch - 20A 300V - 12 to 22 AWG - Screws with Captive Plate Top/ PC Pin Bottom Termination. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NC6-P108-10 from TE Connectivity / Buchanan Brand is barrier block with screws with captive plate top and PC pin bottom termination. This barrier block has 10 circuits, 10 entries and 0.375" (9.53mm) pitch. The NC6-P108-10 accept 12 to 22 AWG wires and operate at 20A current rating and 300V voltage rating. Dimensions of this barrier block are: 96.79 mm L x 16 mm D x 16.51 mm H. Operating temperature range is from -40°C to 105°C.

Product Highlights:

  • Barrier Strip
  • Dual Barrier Block Series
  • Base Style = Flat
  • 9.53 mm Centerline
  • Number of Levels = Single

Search Keywords: NC6P10810

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Buchanan Brand
Part No:
NC6-P108-10
Alias/AKA:
4-1437664-4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BAG
Type:
Barrier Strip
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
9.53 mm
Number of Circuits:
10
Maximum Voltage Rating:
300 V
Maximum Current Rating:
20/Contact A
Wire Size:
12-22 AWG
Operating Temperature:
-40 to 105 °C

IN STOCK: 670

Can Ship immediately

On Order: 400   can ship 9/21/26

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 1300

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
5
$12.07
250
$12.04
500
$12.01
1,000
$11.98
1,300
$11.95
2,600
$6.10
3,900
$4.15
5,200 +
$4.07
