HFW5A1201G00 by te connectivity / cii brand
Image is representational - see mfr. specs

HFW5A1201G00

TE Connectivity / CII Brand

Electromechanical Relay 12VDC 160Ohm 2A DPDT (20.57x10.41x10.41)mm THT Half Size High Performance Relay ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / CII Brand HFW5A1201G00 is a high-performance electromechanical relay designed for various applications. This relay operates at 12VDC with a coil resistance of 160 Ohms, allowing for reliable and efficient performance. With a DPDT configuration, this relay offers versatile switching capabilities, making it suitable for a wide range of circuit requirements.The HFW5A1201G00 relay is designed for through-hole mounting (THT) and features a compact form factor measuring 20.57x10.41x10.41mm. Despite its small size, this relay is capable of handling up to 2A of current, making it ideal for demanding applications.TE Connectivity / CII Brand is known for producing high-quality and reliable relays, and the HFW5A1201G00 is no exception. With its half-size design and exceptional performance characteristics, this relay is a reliable solution for various industrial and commercial applications.

Search Keywords: HFW5A1201G00

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / CII Brand
Part No:
HFW5A1201G00
Alias/AKA:
1617037-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
IN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
Half Size High Performance Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Maximum Current Rating:
2 A
Coil Current:
75 mA
Coil Resistance:
160 Ohm
Mounting:
Through Hole
Operating Temperature:
-65 to 125 °C
Termination Style:
PC Pin

IN STOCK: 62

Can Ship immediately

On Order: 120   can ship 8/5/26

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
1
$129.07
5
$124.60
10
$123.35
20
$122.73
50
$120.90
100 +
$120.29
