HMS1131S04P by te connectivity / cii brand

HMS1131S04P

TE Connectivity / CII Brand

Half Size Relay - DPDT (2 Form C) - 26.5VDC Coil - 2A Contact Rating - Hermetically Sealed - Silver Alloy/Gold Plated - Solder Hook - Panel Mount. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HMS1131S04P from TE Connectivity / CII Brand is double pole double throw DPDT (2 Form C) panel mount half size relay (qualified to MIL-R-39016/44) with 26.5VDC coil voltage, 25.7 mA coil current and 1.03 kOhms coil resistance. This hermetically sealed relay has silver alloy/gold plated contacts, 2A contact current rating and solder hook termination. Operating temperature range is from -65°C to 125°C.

Search Keywords: HMS1131S04P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / CII Brand
Part No:
HMS1131S04P
RoHS:
Yes
HTS:
8536410050
COO:
IN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
Military Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
26.5 V
Maximum Current Rating:
2 A
Coil Current:
25.72 mA
Coil Resistance:
1.03 KOhm
Mounting:
Chassis Mount
Operating Temperature:
-65 to 125 °C
Termination Style:
Solder Hook

IN STOCK: 0

MOQ for out of Stock Qty: 4

Factory Lead-Time 38 Weeks

Price (CAD)

Qty
Unit Price
4
$614.083
8
$377.894
12
$299.170
15 +
$293.183
